GPC E387 Manual Seeding Machine is designed to speed up and convenient for the seed placed into single-row of seeding tray. There is a Vibratory Trough for seed loading and jumping inside, move the Pick-and-Place arm to the Trough and pick up the seeds by vacuum (Vacuum Generator converted from compressed air) heads. Then remove the arm to the above of a row at seeding tray and release the seeds into tray cavities. The design of Pick-and-Place arm moving in widthways caused the time reduced than longways moving, and raise the productivity to maximize the efficiency.
Equipment structure list as follow,
I. Vibratory Trough for seed loading.
II. Movable Seed Pick-and-Place arm.
III. Vacuum Genera
Equipment structure list as follow,
I. Vibratory Trough for seed loading.
II. Movable Seed Pick-and-Place arm.
III. Vacuum Genera
